Passage Control SKY IN.20.602 + Handle With 10 Year Warranty

JNF VOYAGER - UNIVERSAL ACCESS CONTROL SUITABLE FOR VARIOUS LOCKS:

TECHNICAL DATA:

POWER SUPPLY - 3 PCS AAA BATTERY UNIT SUITABLE FOR DIFFERENT TYPES OF LOCKS STAINLESS STEEL BODY

UP TO 70, 000 THOUSAND OPENING CYCLES WITH 3 PCS AAA BATTERIES MICRO USB SOCKET FOR EXTERNAL DEVICE CHARGING TEMPERATURE: - 15 ° / +55 °

FROM "LOW BATTERY" WARNING - 200 OPENING CYCLES SUITABLE FOR DOORS 35 - 60 MM THICKNESS WATER RESISTANCE

SHAFT DIAMETER: 8 X 8 DURING EVENTS THE DEVICE CAN BE DISCONNECTED AND WORK AS A STANDARD HANDLE THE DEVICE HAS A GREEN/RED LIGHT INDICATING THE BATTERY STATUS

INSTRUCTIONS FOR USE

MOBILE APP (WIFI):

• Door unlocking from anywhere in the world with a WIFI connection
• Ability to create short-term or long-term codes (Different time intervals: 2 min / 8 h / 2 months etc.)
• Easy to understand and manage the program
• You can control handles in different rooms with one app
• Battery status
• Device usage register data

FINGERPRINT:

99 different fingerprints can be assigned to one device.

ADMISSION CARDS:

• With advanced MIFARE technology, doors can be opened with cards, watches or wristbands.
• Maximum possible number of cards - 50 pcs

PIN CODE KEYPAD:

The keyboard allows you to use combinations of PIN codes of different types and durations.

Also, with the help of the keyboard, you can perform certain system programming.

BLUETOOTH:

• Door unlocking/locking at a distance of 10 meters from the device
• Creation of temporary codes
• Battery status
• Control of several different devices
